Software module 1 - Fiat, Lancia, Citroen, Peugeot immobox Delphi Memory device is serial memory 93c46 SMD8 package. Expected file size is 128 bytes. Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Fiat: Barchetta, Brava, Bravo(-1998), Cinquecento, Ducato(-2001), Marengo, Panda(-2002), Punto(-1999), Seicento(-1999), Tempra Lancia: Dedra, Delta Citroen: Jumper(-2001), Relay(-2001) Peugeot: Boxer(-2001)

Software module 2 - Fiat, Lancia, Maserati IMM001.01 immobox Marelli Memory device is Motorola MCU MC68HC05E6 SO28 package. Expected file size is 160 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Fiat: Bravo(1998-2001), Marea(1998-), Palio(-1999) Lancia:Dedra, Y Maserati: GT

Software module 3 - Fiat, Lancia IMM110.01 immobox Marelli Memory device is Motorola MCU MC68HC908AZ32 QFP64 package. Expected file size is 512 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Fiat: Bravo(1998-2001), Marea(1998-), Palio(-1999) Lancia: Dedra, Y Maserati: GT

Software module 4 - Alfa Romeo, Iveco CODE1 immobox Bosch Memory device is serial eeprom 93c46, which can be either DIL8 or SMD8 package. Expected file size is 128 bytes. Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Fiat: Coupe, Croma Alfa Romeo: 145, 146, 155, 164, GTV, Spider Iveco: Daily(-2001) Lancia: K, K coupe

Software module 5 - Alfa Romeo CODE2 immobox Bosch Memory device is serial eeprom 93c56 SMD8 package. Expected file size is 256 bytes.Use PCF7935 or Silca T15 - JMA TP14 transponder. Written transponder is ready programmed to start the vehicle.If old keys are erased, software shows PIN code and prepares transponder, ready to be matched with vehicle using diagnostic device. Vehicles equipped with this unit: Alfa Romeo: 156(1998-2001), 166(1998-2001)

Software module 6 - Fiat, Lancia, Alfa Romeo, Maserati CODE2 with BSI Marelli Memory device is Motorola MCU, which can be either MC68HC912DG128 or MC9S12DG256, both QFP 112 package. For MC68HC912DG128 expected file size is 2048 bytes, for MC9S12DG256 file size must be 4096 bytes. Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Module also shows PIN code and transponder have to be matched with car.If there is not valid key, usual you have to wait 15 minutes for accepting PIN code. Vehicles equipped with this unit: Alfa Romeo: 147, GT Fiat: Stilo(1999-2007), Palio(1999-),Idea Lancia: Thesis, Ypsilon Maserati: Quattroporte, Granturismo

Software module 7 - Fiat, Lancia, Alfa Romeo CODE2 with BSI Delphi Memory device is serial eeprom 93c66 SMD8 package. Expected file size is 512 bytes.Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Module also shows PIN code. Written transponder is ready programmed to start the vehicle. If there is not valid key, usual you have to wait 15 minutes for accepting PIN code. Vehicles equipped with this unit: Fiat: Albea, Doblo, Punto(1999-), Siena, Strada

Software module 8 - Fiat, Citroen, Peugeot CODE2 immobox Delphi Memory device is serial eeprom 93c56 SMD8 package. Expected file size is 256 bytes.Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Module also shows PIN code. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Fiat: Ducato(2001-2006), Seicento(1999-) Citroen: Jumper(2001-2006), Relay(2001-2006) Peugeot: Boxer(2001-2006)

Software module 9 - Fiat, Lancia IMM100.01 immobox Marelli Memory device is Motorola MCU MC68HC908AZ32 QFP64 package. Expected file size is 512 bytes.Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Module also shows PIN code. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Lancia: Lybra Fiat: Multipla

Software module 10 - Audi immobox Delphi Memory device is serial memory 93c46 SMD8 package. Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Audi: A4(-1997), A6(-1997)

Software module 11 - Peugeot,Fiat,Citroen immobox Siemens Memory device is Motorola MCU MC68HC05E6 SO28 package. Expected file size is 160 bytes.Use T5 transponder. Software shows PIN code. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Peugeot: 306, Expert, Ranch Citroen: Jumpy, Evasion Fiat: Scudo, Ulysse

Software module 12 - Peugeot, Citroen immobox Valeo Memory device is serial memory 93c46 SMD8 package. Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Citroen: Saxo, Berlingo(-2000) Peugeot: 106, 406(-1999), Partner(-2000)

Software module 13 - Peugeot, Fiat, Lancia, Citroen CPH Texton Memory device is serial eeprom, which can be either 93c66 or 95040, both SMD8 package. Expected file size is 512 bytes. Use T5 transponder. Software shows PIN code. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Peugeot: 306, 806, Expert, Ranch Citroen: Jumpy, Evasion, Xantia(-1999), Xsara(-1999) Fiat: Scudo, Ulysse

Software module 14 - Peugeot 206 BSI Siemens Memory device is Motorola MCU MC68HC05B16 PLCC52 package. Expected file size is 256 bytes.Use PCF7935 or Silca T15 - JMA TP14 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Peugeot: 206(1998-2001)

Software module 15 - Peugeot 406 BSI Siemens Memory device is serial eeprom 93c66 SMD8 package. Expected file size is 512 bytes.Use PCF7935 or Silca T15 - JMA TP14 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Peugeot: 406(1999-2002)

Software module 16 - Daewoo immobox Memory device is Motorola MCU MC68HC05B16 PLCC52 package. Expected file size is 256 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Daewoo: Espero, Lanos(-2002), Leganza(-2000), Matiz(-2001), Nexia, Nubira(-2000)

Software module 17 - Honda, Rover immobox Valeo Memory device is Motorola MCU MC68HC05B16 PLCC52 package. Expected file size is 256 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Honda: Accord(-1999), Civic(-2001) Rover: 600, 618, 620, 800

Software module 18 - Honda, Acura immobox Megamos Memory device is serial memory 93c46 SMD8 package. Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Honda: Accord(-1999), Civic(-2001), CR-V(-2000), Integra, Legend, Passport, Prelude, Shuttle(-2000)

Software module 19 - Opel IMMO1 immobox Siemens Memory device is Motorola MCU MC68HC05B16 PLCC52 package. Expected file size is 256 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Opel: Astra F, Calibra, Combo B, Corsa B, Omega(1996-1999), Sintra(-1999), Tigra, Vectra B Cadillac: Catera

Software module 20 - Opel IMMO2 immobox Siemens Memory device is Texas Instrument MCU TMS370C702 PLCC28 package or Motorola MCU HC908AB16A QFP64 package.Motorola is locked, password for reading eeprom is F3-B1-F3-AB-F3-A5-F3-9F. Expected file size is 256 bytes.Use PCF7935 or Silca T15 - JMA TP14 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Opel: Agila, Astra G, Combo C, Corsa C, Meriva, Omega(1999-), Sintra(1999-), Tigra, Vectra B(1999-), Zafira

Software module 21 - Mitsubishi immobox Bosch Memory device is serial eeprom 93c56 SMD8 package. Expected file size is 256 bytes.Use PCF7935 or Silca T15 - JMA TP14 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Mitsubishi: Carisma(1998-), Space Star(1998-)

Software module 22 - VW, Skoda, Seat IMMO1 immobox Siemens Memory device is Motorola MCU MC68HC05B16 PLCC52 package. Expected file size is 256 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: VW: Caddy(-1998), Golf 3, Passat 3, Polo 3(-1998), Sharan(-1998), Transporter(-1998), Vento Seat: Arosa(-1998), Alhambra(-1998), Cordoba(-1998), Ibiza(-1998), Inca(-1998), Toledo Skoda: Felicia, Pick-up Ford: Galaxy

Software module 23 - VW, Seat IMMO2 immobox Siemens Memory device is Texas Instrument MCU TMS370C702 PLCC28 package. Expected file size is 256 bytes.Use PCF7935 or Silca T15 - JMA TP14 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: VW: Caddy(1998-2000), Golf cabrio, Lupo(-2000). Polo 3(1998-2000), Sharan(1998-2000), Transporter(1998-2000) Seat: Arosa(-2000), Cordoba Vario(-2000), Ibiza(1998-2000), Inca(1998-2000) Ford: Galaxy

Software module 24 - VW, Seat, Ford IMMO3 immobox Valeo Memory device is serial eeprom 24c04 or 24c16 both SMD8 package. Expected file size for 24c04 is 512 bytes , for 24c16 is 2048 bytes. Use PCF7935 or Silca T15 - JMA TP14 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: VW: Lupo(2000-2002), Polo(2000-2002), Transporter(2000-2002) Seat: Arosa(2000-2002), Alhambra(2000-2002), Inca(2000-2002) Ford: Galaxy(2000-2002)

Software module 25 - Seat, Peugeot, Piaggio bikes immobox Marelli Memory device is Motorola MCU MC68HC05E6 SO28 package. Expected file size is 160 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Click here to see opened Piaggio/Peugeot bikes immobox. Vehicles equipped with this unit: Seat: Marbella Fiat: Fiorino Peugeot: Alise, Eliseo, Speedfight Piaggio: Beverly, Liberty, Vespa, X8 Gilera: GP800

Software module 26 - Renault immobox Siemens Memory device is Motorola MCU MC68HC05B16 PLCC52 package. Expected file size is 256 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Renault: Megane(-1999), Twingo(-2000)

Software module 27 - Renault immobox Valeo Memory device is serial memory 93c46 SMD8 package. Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Renault: Laguna(-2001), Safrane, Espace(-1998)

Software module 28 - Renault,Dacia immobox Sagem Memory device is serial memory 93c46 or 93c56 both SMD8 package. Expected file size for 93c46 is 128 bytes,for 93c56 is 256 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Software shows 4-digit PIN code. Vehicles equipped with this unit: Renault: Kangoo(-2001), Clio(-2001), Trafic(-2001), Master(-2001) Opel: Movano(-2001) Dacia: Supernova

Software module 29 - Renault BSI Valeo Memory device is Motorola MCU MC68HC908AZ32 QFP64 package. Expected file size is 512 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Renault: Espace(1998-2002)

Software module 30 - Renault UCH Sagem This software can be used in 2 ways: 1.If you don`t know 12-digit PIN code:Memory device is serial eeprom 93c66 SMD8 package. Expected file size is 512 bytes. Module calculates PIN code. Use PCF7936 or Silca T14 - JMA TP12 transponder.Written transponder have to be matched with car using diagnostic device. 2.If you know 12-digit PIN code:Start software and manually select module. Insert PCF7936 or Silca T14 - JMA TP12 transponder.Press PROG button. Software opens box, where you must enter 12-digit PIN code.Verify it and press OK. Match prepared transponder with car using diagnostic device and PIN code. Vehicles equipped with this unit: Renault: Clio(2001-2006)

Software module 31 - Renault UCH Siemens This software can be used in 2 ways: 1.If you don`t know 12-digit PIN code:Memory device is serial eeprom 93c66 or 95c040 both SMD8 package. Expected file size is 512 bytes. Module calculates PIN code. Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder have to be matched with car using diagnostic device. 2.If you know 12-digit PIN code:Start software and select module. Insert PCF7936 or Silca T14 - JMA TP12 transponder.Press PROG button. Software prepares transponder. Match prepared transponder with car using diagnostic device and PIN code. Vehicles equipped with this unit: Renault: Clio Symbol(2001-2006) Dacia: Logan, Logan MPV

Software module 32 - Mercedes Sprinter, Vito immobox Temic Memory device is Motorola MCU, which can be either MC68HC05X16 or MC68HC908AZ32, both QFP64 package.For MC68HC05X16 expected file size is 256 bytes, for MC68HC908AZ32 expected file size is 512 or 1024 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle.Note: if immobox contain RF receiver in metal box, this means that original key had remote function.In this case you have also to perform START ERROR repair. Important note: if Motorola MCU is MC68HC05X16 - eeprom area is locked, you have to use proper programmer to read it. Vehicles equipped with this unit: Mercedes: Sprinter(1998-2006), Vito(1998-2006) VW: LT28(2000-), LT35(2000-)

Software module 33 - Peugeot bike engine ECU Marelli Memory device is Motorola MCU MC68HC05B16 QFP64 package. Expected file size is 256 bytes.Use T5 transponder. Written transponder is ready programmed to start bike. Click here to see opened Peugeot bike engine ECU Marelli. Vehicles equipped with this unit: Peugeot: Alise, Eliseo, Speedfight Piaggio: Beverly, Liberty, Vespa, X8

Software module 34 - Volvo IMMO3 immobox Bosch Memory device is serial eeprom 93c56 or 93c66, both SMD8 package. For 93c56 expected file size is 256 bytes, for 93c66 is 512 bytes. Use PCF7935 or Silca T15 - JMA TP14 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Volvo: C70(1998-), S40(1998-), S70(1998-), S80(1998-1999), V40(1998-), V70(1998-2000) Volvo trucks: FH12,FM12

Software module 35 - Volvo, Mitsubishi CARTRONIC immobox Bosch Memory device is serial memory 93c46 SMD8 package. Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Mitsubishi: Carisma, Magna Volvo: 850, 940, 960, C70(-1998), Polar, S40(-1998), S70(-1998), V40(-1998), V70(-1998)

Software module 36 - Iveco Daily/Iveco Truck immobox Bosch This module can be used in 2 ways: 1.If you don`t know 5-digit PIN code:Memory device is serial eeprom 93c56 SMD8 package. Expected file size is 256 bytes.Module calculates PIN code. Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder have to be matched with car using diagnostic device. 2.If you know 5-digit PIN code:Start software and select module. Insert PCF7936 or Silca T14 - JMA TP12 transponder. Press PROG button. Software prepares transponder. Match prepared transponder with car using diagnostic device and PIN code. Vehicles equipped with this unit: Iveco: Daily(2001-2007) Iveco trucks: Eurocargo(2001-2007), Stralis(2001-2007)

Software module 37 - Mercedes Actros, Atego engine ECU Temic Memory device is serial eeprom, which can be 93c56,93c66,93c86 or 25c640, all SMD8 package.For 93c56 expected file size is 256 bytes,for 93c66 expected file size is 512 bytes, for 93c86 is 2048 bytes and for 25c640 is 8192 bytes.Use T5 transponder. Written transponder is ready programmed to start the truck. Vehicles equipped with this unit: Mercedes: Actros(1998-),Atego(1998-),Axor(1998-),Econic(1998-)

Software module 38 - Opel, Isuzu immobox Megamos Memory device is serial eeprom 93c46 SMD8 package. Expected file size is 128 bytes.Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Module also shows PIN code. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Opel: Frontera(1998-) Chevrolet:Colorado

Software module 39 - PSA VAG Opel Nissan Ford Mitsubishi new chip This module can prepare PCF7935 or Silca T15 - JMA TP14 transponders,so they become ready to be matched with particular car using diagnostic device and PIN code. Module is useful when you have amount of blank PCF7935 or VAG ID44 transponders.When you got car, which uses ID40, ID41, ID42, ID44 or ID45 and you have PIN code just prepare PCF7935 using this module and after that match transponder with car using diagnostic device. Prepared ID40 chips are switable for absolutely all Opel Immo1/Immo2 cars. Prepared ID41 chips are switable for Nissan NATS 2-4 and some NATS 5 cars. Prepared ID42/ID44 VAG chips are switablefor absolutely all VAG Immo1/Immo2 cars with external immoboxes and also for Ford Galaxy. Prepared ID45 chips are switable for all Peugeot 206/406 with BSI Siemens.

Software module 40 - BMW, Rover, Mini immobox EWS Memory device is Motorola MCU MC68HC11EA9 PLCC52 or MC68HC9S12D64 QFP80 package. IMPORTANT NOTE: Motorola MC68HC9S12D64 IS LOCKED. If you try to read it thru BDM you will erase it. For Motorola MCU MC68HC11EA9 PLCC52 package expected file size is 512 bytes, for MC68HC9S12D64 QFP80 package expected file size is 1024 bytes.Use PCF7935 or Silca T15 - JMA TP14 transponder. Written transponder is ready to start car.Software always program first unused key. After programming of transponder, software stores in PC registry key number along with file information, so on next press of PROG button to be programmed next unused key. Also this is useful, if same customer came back for second key or if again all keys are lost- you do not need to remove and read again EWS eeprom. Just open customer`s file and software automatically will position on next unprogrammed key, cause it finds in registry which key was programmed in previous. Vehicles equipped with this unit: BMW: series 3(-2002), series 5(-2002), series 7(-2002), series 8(-2002),X-3(-2002), X-5(-2002), M3(-2002), Z3(-2002) Rover: 75 Mini: Cooper

Software module 41 - Mazda immobox Temic Memory device is Motorola MCU MC68HC705P3 SO28 package. Expected file size is 128 bytes. Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Mazda: 323(-1999), 626(-1999), MX-3, MX-5, MX-6, Xedox 6, Xedox 9 Ford: Probe

Software module 42 - Mazda immobox Lucas 19AS Memory device is Motorola MCU MC68HC05B6 PLCC52 package. Expected file size is 256 bytes. Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Mazda: 323(-1999), 626(-1999), MX-5

Software module 43 - Nissan, Subaru immobox Siemens Memory device is Motorola MCU MC68HC05B6 PLCC52 package. Expected file size is 256 bytes. Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Nissan: Almera(-1998),Primera(-1998), Pulsar(-1998), Serena(-1998), Sunny, Terrano 2(-1998), Vannete(-1998) Subaru: Impreza(-2000), Legacy(-1998), Outback(-1998)

Software module 44 - Renault UCH Sagem type 2 This module can be used in 2 ways: 1.If you don`t know 12-digit PIN code:Memory device is serial eeprom 93c66 SMD8 package. Expected file size is 512 bytes.Module calculates PIN code.Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder have to be matched with car using diagnostic device. 2.If you know 12-digit PIN code:Start software and select module.Insert PCF7936 or Silca T14 - JMA TP12 transponder.Press PROG button. Software opens box,where you must enter 12-digit PIN code.Verify it and press OK.Match prepared transponder with car using diagnostic device and PIN code. Vehicles equipped with this unit: Renault: Kangoo(2002-2007), Twingo(2002-2007), Trafic(2002-2007), Master(2002-2007) Opel: Vivaro(2002-2007), Movano(2002-2007) Nissan: Interstar(2002-2007)

Software module 45 - Fiat, Lancia, Citroen, Peugeot vans, Iveco vans/trucks CODE2 with BSI Marelli type 2 Memory device is serial eeprom 95c160 or 95c320, both SSOP8 package. For 95c160 expected file size is 2048 bytes, for 95c320 is 4096 bytes. Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Module also shows PIN code. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Fiat: Bravo(2007-), Ducato(2006-), Stilo(2007-), Punto(2007-) Citroen: Jumper(2006-), Relay(2006-) Peugeot: Boxer(2006-) Lancia: Ypsilon(2007-) Iveco: Daily(2007-), Eurocargo(2007-)

Software module 46 - Volvo IMMO1 immobox Bosch Memory device is serial memory 93c46 SMD8 package. Expected file size is 128 bytes. Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Volvo: 850, 940, 960, C70(-1998), Polar, S40(-1998), S70(-1998), V40(-1998), V70(-1998)

Software module 47 - Saab body module TWICE Memory device is Motorola MC68HC05X32 QFP64 package. Expected file size is 256 bytes. Use T5 transponder. Written transponder is ready programmed to start the vehicle. Important note: Motorola MCU is with locked eeprom area, you have to use proper programmer to read it. Vehicles equipped with this unit: Saab: 9-3(-2003), 9-5(-2003)

Software module 48 - Fiat New Panda BSI Siemens VDO Memory device is Motorola MCU MC9S12DG128 QFP 112 package. Expected file size is 2048 bytes. Use PCF7936 or Silca T14 - JMA TP12 transponder. Software also shows PIN code. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Fiat: Panda(2003-)

Software module 49 - Opel, Isuzu immobox Megamos type 2 Memory device is serial eeprom 93c46 SMD8 package. Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Opel: Frontera(1996-1998)

Software module 50 - Jaguar immobox Memory device is serial eeprom 93c46 SMD8 package. Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Jaguar: Sovereign, XJ, XJS, XK, XK8

Software module 51 - Renault Premium/Midlum immobox Texton Memory device is serial eeprom 93c46 SMD8 package. Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the truck. Vehicles equipped with this unit: Renault: Premium(-2007), Midlum(-2007)

Software module 52 - Toyota immobox with ID33 Memory device is serial eeprom 24c04 DIL8 package. Expected file size is 512 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Toyota: Carina, Celica(-1998), Estima(-1998), Paseo(-1998), Previa(-1998), Starlet(-1998)

Software module 53 - MAN TGA module FFR Memory device is serial eeprom, which can be either 25c128 or 25c256, both SMD8 package. Expected file size is 16384 or 32768 bytes.Use T5 transponder. Written transponder is ready programmed to start the truck. Vehicles equipped with this unit: Man: TGA trucks

Software module 54 - Porsche body module with ID13 Memory device is serial eeprom 93c56 SMD8 package. Expected file size is 256 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Porsche: 911(-1999), Boxter(-1999)

Software module 55 - General Motors GM Passkey3 immobox Delphi Memory device is Motorola MCU MC68HC908AS20 PLCC52 package. Expected file size is 512 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Buick: Century, Le Sabre, Park Avenue, Regal, Rendevouz, Roadmaster Cadillac: Deville STS, Dorado, S5S, Seville, STS Chevrolet: Camaro, Cavalier, Corvett, Impala, Malibu, Montecarlo, Venture Oldsmobile: Aurora, Silhouette Pontiac: Aztec, Bonneville, Grand Prix, Montana

Software module 56 - Acura immobox Memory device is serial eeprom 93c46 SMD8 package. Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Acura: 3.5 RL, CL, Integra, MD-X, NSX, TL

Software module 57 - Renault UCH Johnson Controls type 1 This module can be used in 2 ways: 1. If you don`t know 12-digit PIN code: Memory device is serial eeprom 95c080 SMD8 package. Expected file size is 1024 bytes.Module calculates PIN code. Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder have to be matched with car using diagnostic device. 2. If you know 12-digit PIN code:Start software and select module.Insert PCF7936 or Silca T14 - JMA TP12 transponder. Press PROG button. Software opens box,where you must enter 12-digit PIN code.Verify it and press OK. Match prepared transponder with carusing diagnostic device and PIN code. Vehicles equipped with this unit: Renault: Kangoo(2007-), Trafic(2007-), Master(2007-) Opel: Vivaro(2007-), Movano(2007-)

Software module 58 - Ducati bikes dashboard Marelli Memory device is serial eeprom 24c02 or 24c16 SMD8 package. Expected file size is 256 or 2048 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Ducati: 600, 620, 749, 800, 900, 999, 1000

Software module 59 - Fiat Grande Punto BSI Delphi Memory device is serial eeprom 93c86 SMD8 package. Expected file size is 2048 bytes.Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key with PCF7946.Module also shows PIN code. Written transponder is ready programmed to start the vehicle. IMPORTANT NOTE when you want to program remote key type2:open key and you will find 2 SMD chips - PCF7946 (SMD 14 pins) and smaller SMD chip,which can be with 8,10,or 16 pins.If this chip is with 10 or 16 pins,PROGRAM KEY AS TYPE 1.If thischip is with 8 pins,PROGRAM KEY AS TYPE 2. IMPORTANT NOTE:if buttons of remote operate,but not work properly,for ex. button for locking opens trunk,this is NOT A TMPro2 SOFTWARE PROBLEM.Use other type remote. Vehicles equipped with this unit: Fiat: Grande Punto, New 500, Fiorino Alfa Romeo: Mito Ford: KA Citroen: Nemo Peugeot: Beeper

Software module 60 - Polonez immobox Megamos Memory device is serial eeprom 93c46 SMD8 package. Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Polonez: Pick-up Jinbei: Brilliance

Software module 61 - Tata Safari immobox Alltech Memory device is serial eeprom 24c01 SMD8 package. Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Tata: Safari

Software module 62 - Key copier for ID11, ID12, ID13, SAAB and ID33 fixed keys onto T5 transponder Module helps you to copy Philips, Temic and Megamos fixed keys onto T5 transponder. For Renault ID33 key you can see 4-digit PIN code.

Software module 63 - Key copier for ID33, ID41, ID42, ID44 VAG and ID45 keys onto PCF7935 transponder Software helps you to copy crypto keys onto PCF7935 transponder. For ID45 Peugeot 206/406 keys you can see vehicle PIN code.

Software module 64 - Key copier for 4C Texas fixed keys onto JMA TPX1 transponder Module helps you to copy Texas fixed keys onto JMA TPX1 - Errebi TX1 transponder.

Software module 65 - Key copier for 4D Texas Crypto keys onto JMA TPX2 transponder Module helps you to copy 4D Texas Crypto keys onto JMA TPX2 - Errebi TX2 transponder.For Renault ID4D keys it shows 8-digit PIN code. IMPORTANT NOTE: you need JMA TPX CLONER for to copy ALL Texas Crypto keys/read Renault 8-digit PIN code from key.You can buy cloner from here. IMPORTANT NOTE: For Toyota,Lexus,Yamaha,Suzuki bikes and Suzuki Liana,Kawasaki,MV Agusta,Daihatsu and Perodua TPX cloner IS NOT NEEDED. Cloner needs to be connected to your PC COM port thru simple convertor cable. If your PC doesn`t have pure COM port, you can use good USB-RS232 converter or PCMCIA-RS232 card.Cloner also needs 12 v supply to work.

Software module 66 - Yamaha bikes immobox Moric Memory device is serial eeprom Seiko S29190 SMD8 package. Expected file size is 128 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start bike. Click here to see where to dig for to reach eeprom. Note: latest Yamaha immobox Moric DO NOT HAVE external eeprom, so please check your immobox before purchasing this software. If there is no serial eeprom,but 16 pin chip TMS3705 you need software 108. Vehicles equipped with this unit: Yamaha: BT1100, FJR, FZR, FZ1, FZ6, FZS, XT, XTR, XTX, XVX, YZF

Software module 67 - Suzuki bikes engine ECU Denso Memory device is serial eeprom 93c66 SMD8 package. Expected file size is 512 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start bike. Click here to see opened Suzuki bikes engine ECU Denso Vehicles equipped with this unit: Suzuki: Bandit, Hayabusa, GSX-650F, GSX-R600, GSX-R750, GSX-R1000

Software module 68 - Kawasaki bikes engine ECU Denso, Mitsubishi Memory device is serial eeprom 93c56/93c66 8 pin SMD package. Expected file size is 256/512 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start bike. Click here to see opened Kawasaki bikes engine ECU Denso Vehicles equipped with this unit: Kawasaki: ZX-6R, ZX-10R,ZX-11R,ZX-12R, ZX-1000, Z-750S,Ninja,GTR1400

Software module 69 - Mazda 3 dashboard YNS Memory device is serial eeprom 93c56 or 93c66 8 pin SMD package. Expected file size for 93c56 is 256 bytes and for 93c66 is 512 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Mazda: 3, 5, 6(2009-), CX-7, CX-9

Software module 70 - Ford Focus dashboard Visteon Memory device is MC9S12H256 112 pin QFP package. Expected file size is 4096 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Ford: Focus, C-Max, Transit Connect, Fiesta(2009-)

Software module 71 - Jaguar dashboard Memory device is HC912DG60/DG128 112 pin QFP package. Expected file size is 1024/2048 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Jaguar: X-type

Software module 72 - Ford engine ECU Delphi Memory device is serial eeprom 95c160 8 pin SMD package. Expected file size is 2048 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Ford: Focus, Fusion, Mondeo, Transit

Software module 73 - Ford engine ECU Visteon Memory device is serial eeprom 95c040 8 pin SMD package. Expected file size is 512 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Ford: Focus, Fusion, Mondeo, Transit

Software module 74 - Ford,Mazda engine ECU Siemens Memory device is serial eeprom 93c56/93c86 8 pin SMD package. Expected file size is 256/2048 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Ford: Fiesta Mazda: Mazda 2

Software module 75 - Ford Galaxy immobox Memory device is serial eeprom 24c02 8 pin SMD package. Expected file size is 256 bytes.Use T5 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Ford: Galaxy

Software module 76 - Chrysler immobox SKIM Memory device is serial eeprom 24c02 8 pin SMD or Motorola HC908AB16or Motorola HC908AZ32 64 pin QFP package. Expected file size is 256 or 512 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Chrysler, Jeep, Dodge

Software module 77 - KIA immobox Shinchang Memory device is serial eeprom 93c46 8 pin SMD package. Expected file size is 128 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Kia: Carens, Clarence, Joice, Rio, Sportage

Software module 78 - Suzuki immobox Mitsubishi Memory device is serial eeprom 24c01 8 pin SMD package. Expected file size is 128 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Suzuki: Alto, Ignis, Jimny

Software module 79 - Renault Megane immobox Siemens Memory device is Motorola MC68HC05B6 52 pin PLCC package. Expected file size is 256 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car.Module also shows PIN code if you wish to program common Texas crypto chips with diagnostic device. Vehicles equipped with this unit: Renault: Megane(1998-2003), Scenic(1998-2003)

Software module 80 - Renault Megane UCH Siemens Memory device is Motorola MC68HC705B32 52 pin PLCC package. Expected file size is 256 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car.Module also shows PIN code if you wish to program common Texas crypto chips with diagnostic device. Vehicles equipped with this unit: Renault: Megane(1998-2003), Scenic(1998-2003)

Software module 81 - Mazda 6 engine ECU Denso Memory device is serial eeprom 93c56 SMD 8 package. Expected file size is 256 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Mazda: 6

Software module 82 - Mazda 6 engine ECU Mitsubishi Memory device is serial eeprom 24c02 SMD 8 package. Expected file size is 256 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Mazda: 6

Software module 83 - Toyota Avensis immobox Valeo with ID4D-60 Memory device is Motorola MCU MC68HC05E6 SO28 package. Expected file size is 160 bytes.Use TPX2 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Toyota: Avensis, Corolla

Software module 84 - Ford Transit 2008 BCM Siemens VDO Memory device is Motorola MCU MC9S12DT256 QFP 112 package. Expected file size is 4096 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Ford: Transit 2008

Software module 85 - SsangYong immobox VDO Memory device is Motorola MCU MC68HC05B16 SDIP56 package. Expected file size is 256 bytes.Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: SsangYong: Musso, Korando, Rexton (2002 - 2006)

Software module 86 - Chery, Samand immobox Siemens VDO Memory device is Motorola MCU MC68HC908AB16A QFP64 package. Expected file size is 256 or 512 bytes.Use PCF7935 or Silca T15 - JMA TP14 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Chery: Asprinza, Speranza, Shrman Samand: Soren

Software module 87 - Toyota, Lexus ECU Bosch, Fujitsu, Denso Memory device is serial eeprom, which can be 25020/25080/93c56/93c86, all 8 pin SMD package. Expected file size for 25020 and 93c56 is 256 bytes, for 25080 is 1024 bytes and for 93c86 is 2048 bytes.Use JMA TPX1 - Errebi TX1 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Toyota: RAV4, Corolla, Sienna, Yaris Lexus: IS200, IS300, GS300

Software module 88 - Scania truck module Coordinator Memory device is serial eeprom Xicor X5328 8 pin SMD package,which is equal to SPI serial eeprom 95c320, or serial eeprom 25c256. For X5328 expected file size is 4096 bytes, for 25c256 expected file size is 32768 bytes. Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start truck. Vehicles equipped with this unit: Scania: P230, P270, P280, P310, P320, P340, P360, P380, P400, P420R340, R360, R380, R400, R420, R440, R470, R480, R500, R560, R580, R620

Software module 89 - Mazda RX-8 immobox Visteon Memory device is serial eeprom 24c02 SMD 8 package. Expected file size is 256 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Mazda: RX-8

Software module 90 - Yamaha scooter ECU Mitsuba Memory device is serial eeprom 24c04 SMD8 package. Expected file size is 512 bytes.Use T5 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Yamaha:X-MAX 125

Software module 91 - Opel, Isuzu immobox Tokai-Rika with ID4D-64 Memory device is serial eeprom 93c66 DIL8 package. Expected file size is 512 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Opel: Monterey Isuzu: Big Horn, Trooper

Software module 92 - Toyota, Suzuki, Daihatsu immobox with ID4C Memory device is serial eeprom 93c66 DIL8 package. Expected file size is 512 bytes.Use JMA TPX1 - Errebi TX1 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Toyota: 4-Runner(1997-2003), Avalon(1997-2003), Camry, Celsior, Colorada, Corolla(1996-2002), Echo, Hiace, Highlander(2001-2003), Hilux(1999-2004), Duet,Sparky Suzuki: Alto(1996-2002), Baleno, Grand Vitara(1996-2002), Jimny(1999-2002), Swift(1996-2005), Vitara(1996-2002), WagonR(1998-2000) Daihatsu: Charade, Copen, Cuore, Feroza, Move, Sirion(1998-2004), Terios(1997-2005), YRV Isuzu: Trooper

Software module 93 - DAF trucks immobox VDO Memory device is Motorola MCU MC68HC908AZ32 QFP64 package. Expected file size is 512 bytes or 1024.Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Written transponder is ready programmed to start the truck. Vehicles equipped with this unit: DAF: CF, LF, XF series

Software module 94 - Renault, Nissan UCH Johnson Controls type 2 Memory device is serial eeprom 95c080 or 95c160 SMD8 package. Expected file size is 1024 or 2048 bytes.Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key. IMPORTANT NOTE: Nissan Micra K12 accepts ONLY REMOTES. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Renault: Clio3, Modus Nissan: Micra K12 , Livina

Software module 95 - Chrysler, Jeep immobox DaimlerChrysler Memory device is serial eeprom 95c040/95c080/24c16 SMD8 or SSOP8 package or Motorola 912DG128 112 pins QFP. Expected file size is 512 or 1024 or 2048 bytes.Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Jeep: Compass, Commander, Grand Cherokee(2005-), Liberty(2005-), Patriot, Wrangler(2007-) Chrysler: 300C(2005-), Pacifica(2004-), Voyager(2005-), Aspen (2007-), PT Cruiser(2006-), Sebring(2007-)

Software module 96 - Honda bikes ECU Keihin, OKI Memory device is serial eeprom 93c46 or 93c56 or 93c66 SMD8 package. Expected file size is 128 or 256 or 512 bytes.Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder is ready programmed to start bike. Vehicles equipped with this unit: Honda: CBR 600F, CBR 600RR, CBR 900, CBR 1000, CBR 1100F, Gold 2800, NT650V, SH300,Shadow 750, Silver Wind, Varadero, VT750, VTX1800, X11, Hornet, CB400

Software module 97 - Suzuki scooter ECU Keihin Memory device is serial eeprom 93c66 SMD8 package. Expected file size is 512 bytes.Use JMA TPX1 - Errebi TX1 transponder. Written transponder is ready programmed to start bike. Vehicles equipped with this unit: Suzuki: Burgman,GSX-1400

Software module 98 - Aprilia,Moto Guzzi scooter dashboard Digitek Memory device is serial eeprom 24c01 or 24c16, both SMD8 package. Expected file size is 128 or 2048 bytes.Use T5 transponder. Written transponder is ready programmed to start bike. Vehicles equipped with this unit: Aprilia: SR, RSV, Scarabeo, Atlantic 500 Moto Guzzi:Bellagio,Griso,Norge

Software module 99 - Mitsubishi, Suzuki immobox ID4C type 2 Memory device is serial eeprom 24c01 SMD8 package. Expected file size is 128 bytes.Use JMA TPX1 - Errebi TX1 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Mitsubishi: 3000GT, Colt, Eclipse, Express, Galant, Lancer, Mirage, Montero, Nimbus, Pajero, Shogun, Space Gear, Space Runner, Space Wagon Suzuki: Alto, Grand Vitara, Baleno, Jimny, Swift, Vitara

Software module 100 - Fiat dashboard Marelli, VDO Memory device is serial eeprom 95c160 or 24c16 both SMD8 package. Expected file size is 2048 bytes.Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Module also shows PIN code. For Marelli dashboard written transponder is ready programmed to start the vehicle. For VDO dashboard transponder has to be matched with car using diagnostic device. VagTachoUSB supports key programming for Fiat dashboards,please visit www.opelinfo.com Vehicles equipped with this unit: Fiat: Palio, Siena, Strada, Uno 2010

Software module 101 - Ducati bikes dashboard Digitek Memory device is serial eeprom 24c16 SMD8 package. Expected file size is 2048 bytes.Use T5 transponder. Written transponder is ready programmed to start the bike. Vehicles equipped with this unit: Ducati: 848, 948, 1049, 1098, 1198

Software module 102 - Samand, Saipa, Chery, Hainan Mazda new chip This module can prepare PCF7935 or Silca T15 - JMA TP14 transponders, so they become ready to be matched with particular car using diagnostic device and PIN code. There are 3 types supported: Samand/Saipa, Chery and Hainan Mazda. If you are not sure about key type of your car, read original key and check last 3 bytes on screen. Then at select menu of module choose same type.

Software module 103 - Texas Crypto new chip This module can prepare Texas Crypto or Silca 4D-60 - JMA TP06/TP19 transponders,so they become ready to be matched with particular car using diagnostic device and PIN code. You can prepare Texas Crypto chips to 18 different types: Mitsubishi 4D-61, Subaru 4D-62, Ford/Mazda 4D-63, Suzuki 4D-65,Suzuki 4D-66, Suzuki bike, Yamaha bike, Kawasaki bike master key,Kawasaki bike slave key,Toyota 4D with password 32,52,B2,33,53,B3 and Lexus 4D with password 30,50 and B0 Note: this module uses common glass or ceramic Texas crypto chips, not JMA TPX2 chips.

Software module 104 - Honda, Acura immobox Valeo ID46 Memory device is serial eeprom 24c04 or 93c66 both SMD8 package. Expected file size is 512 bytes.Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Honda: Accord, Civic, CR-V, Element, Pilot, Ridgeline Acura: CSX, MDX, RDX, TL, TSX

Software module 105 - Honda immobox HIS-5 ID48 Memory device is serial eeprom 93c46 SMD8 package. Expected file size is 128 bytes.Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Honda: Accord, Civic, CR-V, FR-V, HR-V, Insight, Jazz, Logo, S 2000, Shuttle, Stream

Software module 106 - Mazda 6 diesel ECU Denso Memory device is serial eeprom 93c86 SMD8 package. Expected file size is 2048 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Mazda: 6

Software module 107 - Hyundai, Kia engine ECU Kefico, Bosch Memory device is serial eeprom 95c040 or 95c160 or 95c320 or 95p08, all SMD8 package. For 95c040 expected file size is 512 bytes, for 95c160 expected file size is 2048 bytes, for 95c320 expected file size is 4096 bytes and for 95p08 expected file size is 1024 bytes. Use PCF7936 or Silca T14 - JMA TP12 transponder.. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Hyundai: Atos, Atos Prime, Getz, Accent, Coupe Kia: Sorento, Carens, Picanto, Santa Fe, Ceed

Software module 108 - Yamaha bikes immobox Moric type 2 This is new variant of MORIC immobox, where there is no serial eeprom S29190. When you try to locate S29190 you find 16 pin chip TMS3705. Memory device is MORIC MCU 30 pins SSOP package. Programming is thru TMPro2 interface, no need additional devices. When you purchase software,you will get all additional information. Use Yamaha key or Texas Crypto - Silca 4D-60 - JMA TP06/TP19 transponder. Written transponder is ready programmed to start bike. Also you can set immobox to virgin state. IMPORTANT NOTE:you can program ONE MASTER key and ONE SLAVE key.If you want more slave keys,program a slave key and clone it with software 65.For cloning Yamaha keys with software 65 JMA TPX cloner is not needed.If you want to program MASTER KEY,you MUST MAKE ECU VIRGIN,because you will delete synchro with ECU. MCU in this immobox IS NOT POSSIBLE TO READ. Vehicles equipped with this unit: Yamaha: R1, T-MAX, R6, BT1100, FJR, FZR, FZ1, FZ6, FZS, XT, XJR, XTR, XTX, XVX

Software module 109 - BMW bikes engine ECU Bosch Memory device is flash chip ST M58BW0160 - 80 pin PQFP package. Expected file size is 2097152 bytes. Reading is with flash programmer or thru BDM100 interface. Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder is ready programmed to start bike. Vehicles equipped with this unit: BMW: F800, R1200GS

Software module 110 - Smart ForFour ETACS Siemens-VDO Memory device is Motorola MCU MC9S12B128 QFP112 package. Expected file size is 2048 bytes.Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Smart: ForFour Mitsubishi: Colt IV

Software module 111 - Saab column module CIM Memory device is serial eeprom 93c66 SMD8 package. Expected file size is 512 bytes.Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key with PCF7946.PCF7946 can be brand new blank - no need any preparation,software programs all parts.Software also shows PIN code. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Saab: 9-3(2003-), 9-5(2003-) Cadillac: BLS

Software module 112 - Fiat, Lancia, PSA BSI Marelli type 3 Memory device is serial eeprom 95c160 SSOP8 package. Expected file size is 2048 bytes. Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key. IMPORTANT NOTE when you want to program remote key type2:open key and you will find 2 SMD chips - PCF7946 (SMD 14 pins) and smaller SMD chip,which can be with 8,10,or 16 pins.If this chip is with 10 or 16 pins,PROGRAM KEY AS TYPE 1.If thischip is with 8 pins,PROGRAM KEY AS TYPE 2. IMPORTANT NOTE:if buttons of remote operate,but not work properly,for ex. button for locking opens trunk,this is NOT A TMPro2 SOFTWARE PROBLEM.Use other type remote. Module also shows PIN code Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Fiat: Bravo(2007-), Ducato(2006-), Stilo(2007-), Punto(2007-) Citroen: Jumper(2006-), Relay(2006-) Peugeot: Boxer(2006-) Lancia: Ypsilon(2007-), Musa(2007-)

Software module 113 - Daewoo, Chevrolet immobox ID48 Memory device is serial eeprom 93c56 SMD8 package. Expected file size is 256 bytes. Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Chevrolet: Aveo, Kalos, Lacetti, Leganca, Matiz, Nubira, Takuma

Software module 114 - Mitsubishi immobox ID46 Memory device is serial eeprom 24c01 SMD8 package. Expected file size is 128 bytes. Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Mitsubishi: Lancer, Pajero

Software module 115 - Chevrolet BSI Siemens Memory device is Motorola MC68HC705B32 52 pin PLCC package. Expected file size is 256 bytes. Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Chevrolet: Epica, Evanda

Software module 116 - Isuzu immobox SiemensVDO Memory device is serial eeprom 93c66 SMD8 package. Expected file size is 512 bytes. Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Isuzu: Elf, D-MAX, MU-7

Software module 117 - Chevrolet, Opel immobox ID46 Memory device is serial eeprom 95c040 SMD8 package. Expected file size is 512 bytes. Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Chevrolet: Captiva, HHR, Cobalt Daewoo: Windstorm Opel: Antara GMC: Siera

Software module 118 - Alfa Romeo, Fiat BSI Marelli type 4 with ID46 Memory device is Motorola MCU MC9S12DG256 QFP112 package. Expected file size is 4096 bytes. Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key. Module also shows PIN code and transponder has to be matched with car. Vehicles equipped with this unit: Alfa Romeo: 159 Fiat: Croma

Software module 128 - Gilera, Piaggio bikes engine ECU EFI Memory device can be ST72334 QFP64 package or serial eeprom 25c080 SMD8 package.To see where keys are stored,check eeprom.If eeprom is 25c040,keys are in ST72334.If eeprom is 25c080,keys are in eeprom. Reading of ST72334 MCU is thru TMPro2 interface, no need any additional programmer. At purchasing of software you will get all info how to connect and read MCU ST72334. Expected file size for ST72334 is 256 bytes, for 95c080 is 1024 bytes.Use T5 transponder. Written transponder is ready programmed to start bike. Vehicles equipped with this unit: Gilera: Nexus, Runner Piaggio: Beverly, Vespa

Software module 129 - KTM bikes immobox ZADI Memory device is serial eeprom 24c04 SSOP8 package. Expected file size is 512 bytes.Use TPX2 transponder. Written transponder is ready programmed to start bike. Vehicles equipped with this unit: KTM: 690, 990, 1190

Software module 130 - BMW, Mini CAS SiemensVDO Memory device is Motorola MCU 912DG256 or 9S12DG256 or 9S12XDP512 Expected file size is 2048 or 4096 bytes.IMPORTANT NOTE: Motorola MCU is locked, please use proper programmer.Use PCF7936 or PCF7942 - PCF7943 - PCF7945 transponder or remote key. Written transponder is ready programmed to start car. Vehicles equipped with this unit: BMW: series 1, series 3, series 5, series 6,X-3, X-5,X-6 Mini: Cooper

Software module 131 - Gilera, Piaggiobikes engine ECU Marelli Memory device is ST10F269-T3 - 144 pins TQFP package. Reading of ST10F269-T3 is thru TMPro2 interface, no need additional programmer. Expected file size is 256/262144/327680 bytes.Use T5 transponder. Written transponder is ready programmed to start bike. Vehicles equipped with this unit: Piaggio: Beverly, Vespa,MP3 Gilera: Fuoco

Software module 132 - Nissan Sunny dashboard Memory device is serial eeprom 93c66 SMD8 package. Expected file size is 512 bytes.Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Nissan: Sunny (2007-)

Software module 133 - Citroen Xantia CPH Texton ID48 Memory device is serial eeprom 93c66 SMD8 package. Expected file size is 512 bytes.Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Citroen: Xantia (1998-)

Software module 134 - Renault Twingo 2 UCH Temic Memory device is Motorola MC9S12B256 QFP112 package. Expected file size is 4096 bytes.Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key or card. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Renault: Twingo 2 (2007-)

Software module 135 - Subaru immobox Mitsubishi Memory device is serial eeprom 24c01 SMD8 package. Expected file size is 128 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Subaru: Tribeca(2005-), Forester(2005-), Outback(2005-), Legacy(2005-),Impreza(2005-)

Software module 136 - Ford BSI Delphi Memory device is serial eeprom 95c320 8 pin SMD package. Expected file size is 4096 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Ford: Mondeo, S-MAX Land Rover : Freelander

Software module 137 - General Motors GM Passkey3+ immobox Delphi ID48 Memory device is Motorola MCU MC68HC908AZ32 QFP64 package or MC68HC908AS20 PLCC52 package. Expected file size is 512 bytes or 1024. Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Cadillac: BLS,CTS Chevrolet: Blazer Hummer: H3

Software module 138 - General Motors GM Passkey immobox ID46 Memory device is Motorola MCU MC9S12B128 QFP112 package. Expected file size is 2048 bytes.Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Chevrolet: Malibu Pontiac: G5, G6, Solstice, Pursuit

Software module 139 - SsangYong, Proton engine ECU VDO Memory device is flash AMD AM29F200BB or AM29F400BB 44 pin SSOP package. Expected file size is 262144 or 524288 bytes.Use Megamos Crypto or Silca T6 - JMA TP08 transponder.Written transponder is ready programmed to start car. Vehicles equipped with this unit: SsangYong: Actyon Proton: Wira TagAZ:Road Partner

Software module 140 - KIA immobox Texton ID13 Memory device is Motorola MCU MC68HC805P18 SO28 package. For reading this MCU you can use Motorola MC68HC805P18 adapter . Expected file size is 128 bytes.Use T5 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Kia: Clarus, Shuma, Sportage

Software module 141 - Suzuki Liana immobox Memory device is serial eeprom 93c66 SMD8 package. Expected file size is 512 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Suzuki: Liana,Grand Vitara

Software module 142 - Ford engine ECU Siemens, EEC5 with ID4C Memory device is serial eeprom 93c86 or 95c040 both SMD8 packages. For 93c86 expected file size is 2048 bytes and for 95c040 file size is 512 bytes.Use JMA TPX1 - Errebi TX1 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Ford: KA, Fiesta, Mondeo,Bantam

Software module 143 - Mitsubishi, Subaru immobox Mitsubishi ID4D Memory device is Motorola MCU MC68HC805P18 QFP44 package. For reading this MCU you can use Motorola MC68HC805P18 adapter . Expected file size is 128 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Mitsubishi: Eclipse, Galant, Lancer, Pajero, Montero, Shogun Subaru: Tribeca, Forester, Impreza, Legacy

Software module 144 - Renault UCH Johnson Controls type 3 Memory device is serial eeprom 95c160 SMD8 package. Expected file size is 2048 bytes. Use Philips PCF7936 - Silca T14 - JMA TP12 transponder or remote key with PCF7946 - PCF7947. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Renault: Kangoo (2009-),Twingo(2009-)

Software module 145 - Key copier for Philips Crypto 2 (HITAG2,ID46,TP12) keys onto JMA TPX3/4 transponders Module helps you to copy Philips Crypto 2 (HITAG2,ID46,TP12) keys onto JMA TPX3/4 - Errebi TX4/TX4SA transponders. For performing cloning procedure YOU NEED VEHICLE TO BE WITH YOU,not only key. IMPORTANT NOTE:you needJMA TPH cloner for to work with this software. TPH cloner needs to be connected to PC COM port (or thru USB-COM converter,if your PC doesn`t have pure COM port) using simple convertor cable. Cable,that comes with TMPro2 box IS NOT for connecting JMA TPH cloner to PC.To connect cloner to PC use LEFT port of TPH cloner.You CAN`T USE USB port of cloner to connect it to PC,USB port is for software upgrade of TPH cloner.Cloner also needs 12v supply for to work,"plus" is in the center of connector.If you want to connect in one chain both TPH and TPX cloners,using convertor cable connect TPH cloner to PC and connect TPX cloner to right port of TPH cloner.Cable between TPH and TPX cloner no need converter.

Software module 146 - VW Audi Seat Skoda ID48 dealer key CAN This software offers to you 3 option of using: 1 - Use files, prepared by VagtachoUSB.VagtachoUSB SAVES YOUR TIME,because NO NEEDto wait security time for key programming,when all keys are lost.Also Seat cars CANNOT be programmed with PIN code only. 2 - If you don`t have Vagtacho USB,you can use any OBD2 tool,that can extract 7 bytes of component security from car unit.Enter them manually.Module will prerare dealer key ready for programming with diagnostic device and PIN code. 3 - If you have working key,and you can extract at least 6 bytes component security from engine ECU,you can search for 7-th byte using working key and to prepare new dealer key.

Software module 147 - Kia immobox Texton ID48 Memory device is serial eeprom 93c46 SMD8 package. Expected file size is 128 bytes.Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Kia:Clarus,Shuma,Pride,Carnival,Sportage

Software module 148 - Mercedes C,E,G class masterchip ID44 Module prepares PCF7935 chip and you can start with it Mercedes C and E class years 1995-1997 and G-class years 1995-1999. Written transponder is ready programmed to start the vehicle.

Software module 149 - VW Passat 3C comfort and ECU with ID48 Depending on job with car you have these options: 1.If job is NEED SPARE KEY,you need ONLY file from comfort unit. 2.If job is LOST ALL KEYS,after loading of comfort file software offers to you 3 options: 1 - load file from engine ECU.Supported are EDC16,MED9 not crypted,SIMOS PPD/SIMOS7 2 - enter first 6 bytes of component security.Use any tool to read them by OBD2 If you use one of these 2 options,software will save new file for comfort unit and will program key.You must program comfort with new file and car will start with programmed key. If with your car ECU file is crypted or you can`t read first 6 bytes of CS your solution is 3 - make attempts with key until adopted by car.Use this option when ECU file is cryptedor no way to read first 6 bytes of component security.Software will save new file and you must program comfort with it.After that you must do this sequence "program key with TMPro - try key in car" until car starts with new key. Maximal number of attempts is 256.Time for one attempt "program key with TMPro - try key in car" is no more than 15 seconds. If by any reason you interrupt sequence,software allows you to continue from the point,where it was interrupted,so no need to start it from begining. For engine ECU supported are EDC16 with eeprom 95c320,MED9 with 95c080,Siemens SIMOS PPD with 95c320 and Siemens SIMOS7 with 93c86.For comfort unit eeprom is 95c320. Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Written transponder is ready programmed to start the vehicle. Software also shows PIN code. Vehicles equipped with this unit: VW:Passat 3C (B6/CC)

Software module 150 - VW,Audi,Seat,Skoda CAN dashboard Siemens-VDO. Module needs 2 files - from Micronas flash chip and from eeprom.For Micronas expected file sizes are 524288 and 1048576 bytes.For eeprom 24c16 expected file size is 2048 bytes,for eeprom 24c32 expected file size is 4096 bytes.Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: VW:Golf 5,Caddy,Eos,CrossGolf,Jetta,Touran Seat:Alhambra,Altea,Leon,Toledo Audi:A3 Skoda:Octavia II,Scout

Software module 153 -Toyota,Lexus,Peugeot,Citroen immobox with

ID 4D-67,4D-68 and 4D-70
Memory device is serial eeprom 93c56/93c66/24c04 8 pin SMD package.

Expected file size is 256/512 bytes.Use JMA TPX2 - Errebi TX2 transponder.
Written transponder is ready programmed to start car.
Vehicles equipped with this unit:
Toyota:4Runner,Alphard,Auris,Avalon,Avensis,AvensisVerso,Avanza,Aygo,Camry,Corolla,Corolla Verso,Fortuner,Hiace,Highlander, Landcruiser,Prius,Premio,RAV4,Sequoia,Takoma,Tundra,Yaris
Lexus:ES330,ES350,GS300,GS350,GS430,GS450,GS460,GX470,IS220,IS250,IS300,
IS350,LS430,LX470,RX300,RX330,RX350,SC430
Citroen:C1
Peugeot:107

Software module 154 - Hana Benni immobox and ECU with ID4D Module require two files - from immobox and from engine ECU. For immobox memory device is serial eeprom 95040 file size 512 bytes,for ECU memory device is Motorola MCU 9S12KG256 file size 4096 bytes.Use JMA TPX2 - Errebi TX2 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Hana Benni

Software module 155 - Volkswagen,Audi,Porsche,Bentley KESSY SiemensVDO,Continental Memory device is serial eeprom 93c86 SMD 8 package. Expected file size is 2048 bytes. Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key with PCF7946. Module also shows PIN code and transponder has to be matched with car. Vehicles equipped with this unit: Audi:A8 Volkswagen:Touareg,Phaeton Porsche:Cayenne Bentley:Continental

Software module 156 - Volvo CEM module ID48 with flash chip Memory device is flash chip Intel TB28F400 S044 package. Expected file size is 524288 bytes. Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Volvo:S80(-2003),S60(-2003),XC70(-2003),XC90(-2003),V70(-2003)

Software module 157 - Ford/Mazda/Lincoln Chrysler/Subaru/Jeep/Renault/Isuzu new chip This software can convert JMA TPX2 chip into Ford/Mazda/Lincoln Texas Crypto 4D-63 and Chrysler/Subaru/Jeep/Renault/Isuzu Texas Crypto 4D-64 After that you can program this chip to car using diagnostic tool.

Software module 158 - Mitsubishi Grandis immobox Memory device is serial eeprom 24c02 SMD8 package. Expected file size is 256 bytes. Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Mitsubishi:Grandis,L200,Nativa

Software module 159 - Honda engine ECU with ID48 Memory device is Motorola HC805P18. For reading this MCU you can use Motorola HC805P18 adapter. Expected file size is 128 bytes. Use Megamos Crypto or Silca T6 - JMA TP08 transponder. Written transponder is ready programmed to start the vehicle. Vehicles equipped with this unit: Honda:HR-V(1999-2002),CR-V(1999-2002),Odyssey(1999-2002)

Software module 160 - Mitsubishi Outlander immobox with ID46 Memory device is serial eeprom 24c16 SMD8 package. Expected file size is 2048 bytes. Use PCF7936 or Silca T14 - JMA TP12 transponder. Written transponder is ready programmed to start car. Vehicles equipped with this unit: Mitsubishi:Outlander(2006-),Lancer(2006-)

Software module 161 -

Proton Savvy immobox with ID4C
Memory device is serial eeprom 93c46 SMD8 package.
Expected file size is 128 bytes.
Use JMA TPX1 - Errebi TX1 transponder.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Proton:Savvy

Software module 162 - Kawasaki JetSki Ultra engine ECU with ID4D
Memory device is serial eeprom 24c04 SMD8 package.
Expected file size is 512 bytes.
Use JMA TPX2 - Errebi TX2 transponder.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Kawasaki:JetSki Ultra

Software module 163 - Suzuki engine ECU with ID46
Memory device is serial eeprom 93c56 or 93c66 both SMD8 package.
For 93c56 expected file size is 256 bytes,for 93c66 is 512 bytes.
Use Philips PCF7936 - Silca T14 - JMA TP12 transponder.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Suzuki:Swift(2007-),Splash(2007-),Grand Vitara(2007-)

Software module 164 - Jaguar S-type dashboard with ID4D
Memory device is Motorola HC11KS8 mask 0H98X PLCC68 package.
Expected file size is 640 bytes.
Use JMA TPX2 - Errebi TX2 transponder.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Jaguar:S-type

Software module 165 - Porsche body module PAS with ID48 in key
Memory device is serial eeprom 93c66 SMD8 package.
Expected file size is 512 bytes.
Use Megamos Crypto or Silca T6 - JMA TP08 transponder.
Written transponder is ready programmed to start car.
Vehicles equipped with this unit:
Porsche:Carrera GT,Carrera GT2 (996),Carrera GT3 (996),Boxster (986),Boxster S (986),
911 Turbo (996),911 Carrera 4 (996)

Software module 166 - Hyundai,Kia immobox Shin Chang with ID4D
Memory device is serial eeprom 93c56 DIL8 package.
Expected file size is 256 bytes.Use JMA TPX2 - Errebi TX2 transponder.
Written transponder is ready programmed to start the car.
Vehicles equipped with this unit:
Hyundai:Sonata(2000-2005),H1(2000-2005),SantaFe(2000-2005),
Elantra(2000-2005),Grandeur(2000-2005),Sonica(2000-2005),Trajet(2000-2005)
Kia:Sorento(2000-2005)

Software module 167 - Opel Astra J,Chevrolet Cruze BCM
Memory device is serial eeprom 24c16 or 95c160 both SMD8 package.
Expected file size is 2048 bytes.
Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key.
Software also shows PIN code.
Written transponder is ready programmed to start car and remote will operate.
Vehicles equipped with this unit:
Opel:Astra J,Insignia
Chevrolet:Cruze
Buick:Regal

Software module 168 - Peugeot JetForce dashboard
Memory device is serial eeprom 95c020 SMD8 package.
Expected file size is 256 bytes.Use T5 transponder.
Written transponder is ready programmed to start the bike.
Vehicles equipped with this unit:
Peugeot:JetForce

Software module 169 - Daihatsu,Perodua immobox Tokai-Rika with ID4D-67
Memory device is serial eeprom 93c66 SMD8 package.
Expected file size is 512 bytes.
Use JMA TPX2 - Errebi TX2 transponder.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Daihatsu:Cuore (2004-),Materia(2004-),Sirion(2004-),Terios(2004-)
Perodua:Myvi,Viva,Alza

Software module 170 - Mitsubishi Canter Fuso immobox Tokai-Rika
Memory device is serial eeprom 93c66 SMD8 package.
Expected file size is 512 bytes.
Use JMA TPX2 - Errebi TX2 transponder.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Mitsubishi:Canter Fuso (2007-)

Software module 171 - MV Agusta bikes dashboard
Memory device is PIC16F690 SSOP20 package.
You can read/write it with PIC programmer,check www.olimex.com/dev/pic-icd2-pocket.html
Use JMA TPX2 - Errebi TX2 transponder.
Written transponder is ready programmed to start the bike.
Vehicles equipped with this unit:
MV Agusta:Brutale

Software module 172 - Chevrolet immobox Shin Chang
Memory device is ST72C334 SSOP44 package.
Reading of eeprom area is thru TMPro2 external interface,no need any additional programmers.At purchasing of software you will get all info how to connect and read MCU ST72334.
Expected file size is 256 bytes.
Use JMA TPX2 - Errebi TX2 transponder.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Chevrolet:Lacetti,Optra

Software module 173 - Honda,Acura engine ECU with ID13
Memory device is Motorola HC805P18 SO28 package.
For reading this MCU you can use Motorola HC805P18 adapter.
Expected file size is 128 bytes.
Use T5 transponder.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Honda:HR-V(1999-2002),CR-V(1999-2002),Odyssey(1999-2002),Accord(1999-2002)
Acura:Integra(1999-2004),MDX(1999-2002),TL(1999-2004),RSX(1999-2002)

Software module 174 - Landrover Freelander,Range Rover immobox SAWDOC.
Memory device is PIC18F252 28 pin SO package.
You can read/write it with PIC programmer,check here.
Use PCF7936 or Silca T14 - JMA TP12 transponder.
Written transponder is ready programmed to start car.
Vehicles equipped with this unit:
Landrover:Freelander (2003-2006)
Range Rover:2004-2006

Software module 175 - Fiat Grand Siena,Palio BSI Marelli type 5 with ID46
Memory device is serial eeprom 95c160 or 95c320 SSOP8 package.
Expected file size is 2048 or 4096 bytes.
Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key with PCF7946.
IMPORTANT NOTE: when you want to program remote key type2:open key and you will find 2 SMD chips - PCF7946 (SMD 14 pins) and smaller SMD chip,which can be with 8,10,or 16 pins.If this chip is with 10 or 16 pins,PROGRAM KEY AS TYPE 1.If this chip is with 8 pins,PROGRAM KEY AS TYPE 2.
IMPORTANT NOTE: if buttons of remote operate,but not work properly,for ex. button for locking opens trunk,this is NOT A TMPro2 SOFTWARE PROBLEM.Use other type remote.
Module also shows PIN code.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Fiat:Grand Siena (2011-),Palio (2011-)

Software module 176 - Volvo CEM Delphi with ID46
Memory device is serial eeprom 95c320 SMD package.
Expected file size is 4096 bytes.
Use PCF7936 or Silca T14 - JMA TP12 transponder or remote key with PCF7953.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Volvo:S80(2006-2009),V70(2006-2009)

Software module 177 - Ducati bikes with dashboard MAE Electronics
Memory device is PIC18F6585 QFP64 package.
For working with this software you need TMPro2 PIC adapter .
You CANNOT use other PIC programmer with this software.
Reading key data is without opening of dash.
It is necessary to cut a small hole for to access programming points.
After you buy software you will get connection diagrams.
Use T5 transponder.
Written transponder is ready programmed to start the bike.
Vehicles equipped with this unit:
Ducati:Hypermotard,Streetfighter

Software module 178 - Ducati bikes handsfree ZADI
Memory device is serial eeprom 24c04.
Expected file size is 512 bytes
Use Texas Crypto transponder or original Ducati key.
Written transponder is ready programmed to start bike.
Vehicles equipped with this unit:
Ducati:Diavel,Multistrada

Software module 179 - Jaguar immobox ID48
Memory device is serial eeprom 93c46 SMD8 package.
Expected file size is 128 bytes.
Use Megamos Crypto or Silca T6 - JMA TP08 transponder.
Written transponder is ready programmed to start car.
Vehicles equipped with this unit:

Jaguar:XJ8,XJR,XK8,XKR

Software module 180 - Unlocking of locked PIC18F252 in SAWDOC
This software can unlock PIC18F252 used in immobiliser box SAWDOC in Land Rover
and Range Rover.
After unlock procedure completed you can read PIC in normal way by TMPro
and use software 174 to make key.
You need TMPro2 PIC adapter for to use this software.

Software module 181 - Land Rover Discovery 3 (LR3),Range Rover Sport CEM
Memory device is PIC18F6620 64 pin QFP package.
You must read and program it with TMPro2 PIC adapter .
Use PCF7936 or Silca T14 - JMA TP12 transponder.
Written transponder is ready programmed to start car.
Vehicles equipped with this unit:
Landrover:Discovery 3,LR3 (2004-2010)
Range Rover:Sport (2005-2010)

Software module 182 - Ducati 1199 Panigale immobox ZADI
Memory device is Motorola 9S12P128.
You can read eeprom area with TMPro.
Expected file size is 4096 bytes.
Use Texas Crypto transponder.
Written transponder is ready programmed to start bike.
Vehicles equipped with this unit:
Ducati:1199 Panigale

Software module 183 - KTM bikes immobox ZADI type 2
Memory device is Motorola 9S12P128.
You can read eeprom area with TMPro.
Expected file size is 4096 bytes.
Use JMA TPX2 - Errebi TX2 or YS-01 transponder.
Written transponder is ready programmed to start bike.
Vehicles equipped with this unit:
KTM:Duke,660,990,1190

Software module 184 - Mazda,Ford,Proton immobox Lucas,Mitsubishi with Temic Crypto 8C transponder
Memory device is Motorola HC805P18 QFP44 package or Motorola HC05B16 PLCC52 package.
For reading Motorola HC805P18 you can use Motorola MC68HC805P18 adapter .
Expected file size for Motorola HC805P18 is 128 bytes,for Motorola HC05B16 is 256 bytes.
Use TK5561 Temic Crypto transponder.
Written transponder is ready programmed to start the vehicle.
Vehicles equipped with this unit:
Mazda:121,323,626,Demio,Premacy,Miata,MPV,MX-5
Ford:Ranger,Explorer
Proton:415,416

Software module 185 - Key copier for Temic Crypto 8C transponders.
This software module helps you to copy Temic Crypto 8C keys from Mazda,Ford Ranger and Proton.
Software writes on NOT-LOCKED TK5561 Temic Crypto transponders.
You can check your transponder simply by reading it - you will get information if it is
locked or not.

Software module 186 - BMW C600,C650 Husqvarna Nuda dashboard
Memory device is serial eeprom 25c160 SMD8 package.
Exected file size is 2048 bytes.
Use TMS37145 80-bit transponder,for example Ford 80-bit.
Written transponder is ready programmed to start bike.
Vehicles equipped with this unit:
BMW:C600,C650
Husqvarna:Nuda

Software module 187 - Key copier onto TS48 transponders for Daewoo/KIA keys.
This software module helps you to copy Daewoo and KIA ID48 keys.
Software writes on TS48 transponders.

Программный модуль 188 - Toyota,Lexus,Subaru, SMART key блок Denso Устройства памяти serial eeprom 93c86 SMD8 пакет. Exected файл размером 2048 байт. Используйте только оригинальные ключи Toyota,Lexus и Subaru. Запрограммированный ключ сможет завести автомобиль, когда вы положили его возле кнопки пуск. Hands-free функция работать не будет . Чтобы активировать его, необходимо запрограммировать новые ключи через OBD2. Также перепрограммировать первый ключ. Транспортные средства, оборудованные этой системой: Toyota: Land Cruiser 200, Land Cruiser Prado, RAV4, Venza, Corolla Lexus: LX 570, GX 460, RX, LS 460, GS, Subaru: Outback,Legacy,Forester

Программный модуль 189 - Ducati Hypermotard 2013 dashboard МАЕ Устройство памяти serial eeprom 24c02 SMD5 пакет. Ожидаемый Размер файла составляет 256 байт. Использовать TMS37145 80-бит транспондер. Запрограммированный транспондер готов к запуску. Транспортные средства, оборудованные этот системой: Ducati: Hypermotard 2013

Программный модуль 190 - Subaru 2013 BCM Mitsubishi Устройство памяти serial eeprom 24c02 SMD8 пакет. Ожидаемый размер файла составляет 256 байт. Использовать TMS37145 80-бит транспондер или оригинал Subaru ключ. Запрограммированный транспондер готов к запуску автомобиля. Транспортные средства, оборудованные этой системой: Subaru: Forester,XV,Legacy,Impreza,Outback,WRX

Программный модуль 191 - BMW bikes 2012 immobox EWS.
Память устройства Motorola 9S12G128.
Размер ожидаемого файла 4096 байт.
Прочитать процессор Motorola можно TMPro.
Использовать TMS37145 80-бит транспондер.
Запрограммированный транспондер готов запустить bikes.
Транспортные средства, оборудованные immobox EWS:
BMW: R1200,C650,K1600,K1300,C600,F800

____________________________________________________________________________________________________________________________________________________________________________

Software module 192 - Ducati 821 dashboard MTA Устройство памяти EEPROM 24c16 SMD8. Ожидаемый размер файла равен 2048 байт. Для записи используем JMA TPX2, Errebi ТХ2 или YS-01-транспондер. Программное обеспечение показывает пин-код. Запрограммированный транспондер готов к запуску. Транспортные средства, оснащенные данным устройством: Ducati: Monster 821

Software module 193 - Ducati 1200 dashboard MTA Устройство памяти EEPROM 24c16 SMD8. Ожидаемый размер файла 65536 байт. TMS37145 использовать 80-битный транспондер. Программное обеспечение показывает пин-код. Запрограммированный транспондер готов к запуску. Транспортные средства, оснащенные данным устройством: Ducati: Monster 1200

Software module 194 - Fiat South America immobox Marelli IMM009.10 Память устройства Motorola 9S08DZ32 32-pin SMD. Вычитать Motorola можно при помощи TMPro. Используется Megamos Crypto по Silca T6, по JMA TP08 транспондер. Запрограммированный транспондер готов к запуску автомобиля. Транспортные средства, оснащенные данным устройством: Fiat: Fiorino Furgao,Palio 2012->,Siena 2012->,Ducato 2012-> Peugeot:Boxer 2012-> Citroen:Jumper 2012->

Software module 195 - Great Wall immobox Delphi Память устройства eeprom 93c66 SOT-23. Ожидаемый размер файл 512 байт. Используется Megamos Crypto по Silca T6 по JMA TP08 транспондер. Запрограммированный транспондер готов к запуску автомобиля. Транспортные средства, оснащенные данным устройством: Great Wall: Hover,Wingle,Voolex C10,C20,C30

Скачать драйвера USB (2.10.00 / 21.02.2014)
Загрузка основного программного обеспечения (вер. 2.356 / 14.06.2016)
